Hfj400c 400m Depth Agriculture Crawler Type Water Well Drilling Rig
Hfj400c 400m Depth Agriculture Crawler Type Water Well Drilling Rig - Image 2
Hfj400c 400m Depth Agriculture Crawler Type Water Well Drilling Rig - Image 3
Hfj400c 400m Depth Agriculture Crawler Type Water Well Drilling Rig - Image 4
Hfj400c 400m Depth Agriculture Crawler Type Water Well Drilling Rig - Image 5

Hfj400c 400m Depth Agriculture Crawler Type Water Well Drilling Rig

MACHINES IN CHINA
Only orders placed and paid through Alibaba.com can enjoy free protection by

Manufacturer Verification Applied

  • Claim a refund if your order doesn't ship, is missing, or arrives with product issues
Feature Details
Weight 10,500 kg (10.5 Tons)
Dimensions (L×W×H) 5,700 × 2,000 × 2,550 mm
Working Air Pressure 1.05 – 3.45 MPa
Air Consumption 16 – 55 m³/min
Axle Pressure 10 Tons
Drilling Rod Diameter 89 mm / 102 mm
Walking Speed 3.5 km/h

Original price was: $47,000.00.Current price is: $46,000.00.

Compare
Add to wishlist
Shipping and returns

Authorities in our business will tell in no uncertain terms that Lorem Ipsum is that huge, huge no no to forswear forever. Not so fast, I'd say, there are some redeeming factors in favor of greeking text, as its use is merely the symptom of a worse problem to take into consideration.

Product care

Anyway, you still use Lorem Ipsum and rightly so, as it will always have a place in the web workers toolbox, as things happen, not always the way you like it, not always in the preferred order.

Product Description



Product Description

1.Drilling depth can reach 400m
2.Steels quality is good, torque is large
3.Easy operation, free-maintaining
4.For various complex strutam, such as pebble bed, aggregate bed.
5.Saving money, compact construction, easy moving
6. Applicable to industry, residents drilling, ground drilling, large diameter, deep drilling, footage fast, flexible and efficient.

Hfj400c 400m Depth Agriculture Crawler Type Water Well Drilling Rig

Product Parameters
Model HFJ180C HFJ200C HFJ300C HFJ400C HFJ500C
Max. Drilling depth 180m 200m 300m 400m 500m
Drilling diameter 90-254mm 90-315mm 105-325mm 105-350mm 105-350mm
Working air pressure 1.05-2.46Mpa 1.7-3.0Mpa 1.05-3.45Mpa 1.05-3.45Mpa 1.05-4.5Mpa
Air consumption 16-30m³/min 17-35m3/min 16-55m3/min 16-55m3/min 16-60m3/min
Drilling rod length 3m 3m 3m/4.5m/6m 3m/4.5m/6m 3m/4.5m/6m
Drilling rod diameter 76/89mm 76/89mm 89/102mm 89/102mm 89/102/114mm
Axle pressure 4T 4T 4T 10T 12T
Lifting force 12T 14T 20T 24T 28T
Lifting speed 2.5m/min 2.5m/min 3.0m/min 3.0m/min 3.0m/min
Pulling speed 0.5-5m/min 0.5-5m/min 0.5-5m/min 0.5-5m/min 0.5-5m/min
Fast lifting speed 18m/min 18m/min 30m/min 25m/min 25m/min
Fast pulling speed 35m/min 35m/min 50m/min 40m/min 40m/min
Max. rotation torque 4200-5600Nm 4500-6500Nm 6500-8500Nm 7500-9500Nm 8500-11000Nm
Rotation speed 48-70r/min 50-70r/min 60-100r/min 45-120r/min 75-150r/min
Mud pump flow 20L/min(optional) 20L/min(optional) 20L/min(optional) 20L/min(optional) 20L/min(optional)
High hydraulic leg stroke 1.5m 1.5m 1.5m 1.5m 1.5m
Walking speed 2.5Km/h 2Km/h 3.5Km/h 3.5Km/h 3.5Km/h
Climbing capacity 30° 30° 30° 30° 30°
Weight 4.7t 5.4t 8.5T 10.5t 11.5T
Dimension 3600*1700*2150mm 3900*1700*2150mm 4800*2000*2450mm 5700*2000*2550mm 5800*2250*2550mm
Power QuanChai 55 kw Yuchai 72 kw 93KW 105KW(6 cylinder) 125kw

Hfj400c 400m Depth Agriculture Crawler Type Water Well Drilling Rig
