Factory Back Hoe Wheel Loader 2.5 Ton Excavator Backhoe Loader with Euro 5 Emission Standard

Factory Back Hoe Wheel Loader 2.5 Ton Excavator Backhoe Loader With Euro 5 Emission Standard
Products Show
Factory Back Hoe Wheel Loader 2.5 Ton Excavator Backhoe Loader with Euro 5 Emission Standard
Factory Back Hoe Wheel Loader 2.5 Ton Excavator Backhoe Loader with Euro 5 Emission Standard
Product Parameters

Factory Back Hoe Wheel Loader 2.5 Ton Excavator Backhoe Loader with Euro 5 Emission Standard

The specification of 2.5ton backhoe loader BLT388 Excavator
Transport Dimension
Overall Operating Weight
8200KG
mm L*W*H
6230×2365×3752
Wheel base
2200mm
Min. Ground Clearance
300mm
Bucket Capacity
1.0m3
Breakout Force
38KN
Loading Lifting Capacity
2500KG
Bucket Dumping Height
2650mm
Bucket Dumping Distance
1025mm
Digging Depth
52mm
Backhoe Capacity
0.3 m3
Max. Digging Depth
4085mm
Swing Angle of Excavator Grab
190o
Max. Pulling Force
39KN
Engine
Model
YC4A105Z-T20
Type
turbocharging four-stroke
Cylinder-Inside Diameter*Stroke
4-105
Rated Power
75KW/100HP
Rated Speed
2400r/min
Min. Fuel Consumption
235g/kw.h
Max.Torque
310NM
Displacement
4.3L
Transmission System
Torque Converter
Model
YJ280
Type
Single-stage Three Elements
Max. Efficiency
84.40%
Inlet Pressure
0.4Mpa-0.55 Mpa
Outlet Pressure
1.2Mpa-1.5 Mpa
Cooling Method
Oil-cooling Pressure Circulation
Gearbox
Type
Fixed Shaft Power Transmission
Oil Pressure of Clutch
1373Kpa-1569 Kpa
Gears
Two Gears Ahead, Two Gears Astern
Max.Speed
22Km/h
Tyre
Model
14-17.5/19.5L-24
Pressure of Front wheel
0.22 Mpa
Pressure of Back Wheel
0.22 Mpa
Feature:
1. The integral body frame with more stable operating condition, more suitable for digging work;
2. The excavating working structure is side shift type, higher strength, good structural stability;
and the loading end adopt eight -bar linkage mechanism.

3. The boom adopts larger section, improving the rigidity and deformation resistance.standard
excavator bucket with strengthened and thicker steel.

4. Rear and front body, with small rotary radius,hydraulic steering,comfy and convenient to operate.
heavy duty hinge joint and hydraulic pipe protection
5. Lifting enlarge operator cabin with secure glass and wide field, comfortable steering wheel, high
quality seat and suitable joystick control
