Versatile Vacuum Heat Press Machine for Rubber Processing Machinery
Versatile Vacuum Heat Press Machine for Rubber Processing Machinery - Image 2
Versatile Vacuum Heat Press Machine for Rubber Processing Machinery - Image 3
Versatile Vacuum Heat Press Machine for Rubber Processing Machinery - Image 4
Versatile Vacuum Heat Press Machine for Rubber Processing Machinery - Image 5
Versatile Vacuum Heat Press Machine for Rubber Processing Machinery - Image 6
Versatile Vacuum Heat Press Machine for Rubber Processing Machinery - Image 7
Versatile Vacuum Heat Press Machine for Rubber Processing Machinery - Image 8

Versatile Vacuum Heat Press Machine for Rubber Processing Machinery

MACHINES IN CHINA
Only orders placed and paid through Alibaba.com can enjoy free protection by

Manufacturer Verification Applied

  • Claim a refund if your order doesn't ship, is missing, or arrives with product issues
Feature Details
Model WX-406 (A/B/C variants)
Control Type PLC + Touch Screen (C-model) / Manual or Electric (A/B)
Pressure Capacity 30 / 50 / 100 Tons (Customizable)
Working Plate Size $300 \times 300 \text{ mm}$ (Standard)
Temperature Range Room Temperature – $300^{\circ}\text{C}$
Cooling Mode Water Cooling System
Cylinder Stroke $180 \text{ mm}$ (Typical for lab series)
Dimensions (W×D×H) $540 \times 400 \times 1250 \text{ mm}$
Power Supply 3-Phase AC 380V, 50Hz/60Hz
Weight Approx. $210 \text{ – } 710 \text{ kg}$ (Configuration dependent)

Original price was: $21,000.00.Current price is: $20,000.00.

Compare
Add to wishlist
Shipping and returns

Authorities in our business will tell in no uncertain terms that Lorem Ipsum is that huge, huge no no to forswear forever. Not so fast, I'd say, there are some redeeming factors in favor of greeking text, as its use is merely the symptom of a worse problem to take into consideration.

Product care

Anyway, you still use Lorem Ipsum and rightly so, as it will always have a place in the web workers toolbox, as things happen, not always the way you like it, not always in the preferred order.

Product Description

WX-406 Heat Press Machine
      Heat press machine,test raw materials and formulations are molded under rated pressure, temperature and cooling conditions,make the molded sheet meet the specified quality and testing standards,and the results will used for the next step of physical performance testing or product quality testing.
     APPLICATION SCOPE
A.New product development and formula optimization;
B.Product quality control and raw material testing;
C.Processing performance research and process optimization;
D.Formulation material blending performance;
E.Teaching and research application.
Versatile Vacuum Heat Press Machine for Rubber Processing Machinery
Versatile Vacuum Heat Press Machine for Rubber Processing Machinery
Versatile Vacuum Heat Press Machine for Rubber Processing Machinery
Versatile Vacuum Heat Press Machine for Rubber Processing Machinery
Specification
Model No.
WX—406A
WX—406B
WX—406C
WX—407
Control Mode
Manual
Electric
PLC control
Vacuum
Capacity
30/50/100 ton or customized
Temperature range
Room temperature ~ 300℃
Size of working plates
300×300mm or customized
Work layer
Single layer heating or integrated cooling and heating
Cooling mode
Water cooling
Water cooling or linear cooling
Volume (W×D×H)
540×400×1250mm
1100×600×1580mm
1500×600×1580mm
Weight(kg)
210kg
780kg
900kg
Power supply
3∮,AC380V
