Product Description
Versatile Palletizing Robot Designed for Small Box Applications
The SAIBON-A180 20kg load palletizing robot is a specialized automated palletizing equipment that is digitized and capable of achieving four-axis linkage. It has a wide working range, is easy to operate, and perform precise welding.It also has high efficiency and ensures good stability of product.
STRUCTURAL COMPOSITION:
The robot body, servo drive system, arm, end effector, end effector adjustment mechanism, control system, etc..
Specification
PRODUCT FEATURES:
1. Simple structure, fewer components, longer service life.
2. Simple operation.
It can be operated with one hand, simple and effortless.
3. High production efficiency.
The palletizing robot can increase packaging efficiency by 15%.
4. Less floor space required.
The palletizing robot can be set in narrow spaces, saving space while achieving significant effects.
5. Strong applicability.
The size, volume, shape of different products and the size of the pallet can be adjusted on the touch screen.
6. Low energy consumption.
The power of the palletizing robot is around 5KW, significantly reducing the operating costs for customers.
7. It is equipped with a multi-layer stainless steel filter screen, ensuring the machine can work normally in harsh environments with a lot of dust and fine fibers.
2. Simple operation.
It can be operated with one hand, simple and effortless.
3. High production efficiency.
The palletizing robot can increase packaging efficiency by 15%.
4. Less floor space required.
The palletizing robot can be set in narrow spaces, saving space while achieving significant effects.
5. Strong applicability.
The size, volume, shape of different products and the size of the pallet can be adjusted on the touch screen.
6. Low energy consumption.
The power of the palletizing robot is around 5KW, significantly reducing the operating costs for customers.
7. It is equipped with a multi-layer stainless steel filter screen, ensuring the machine can work normally in harsh environments with a lot of dust and fine fibers.
TECHNICAL PARAMETERS:
(Custom configurations available upon request.)
|
Axis number
|
4
|
|
|
Payload
|
20kg
|
|
|
Repeat positioning accuracy
|
±0.08mm
|
|
|
Maximum arm span
|
1736mm
|
|
|
Integrity protection level
|
IP65
|
|
|
Electrical cabinet protection level
|
IP43
|
|
|
Ambient temperature
|
0-45°C
|
|
|
Installation method
|
Ground,Bracket
|
|
|
Weight
|
280kg
|
|
|
Function
|
Loading,stacking,and unloading of materials
|
|
|
Maximum range of movement
|
J1
|
±130°
|
|
J2
|
+35°~-70°
|
|
