Industrial Palletizing Robot for Multiple Packaging Lines
Product Overview:
The IRB 460 is a high-speed palletizing robot designed to enhance productivity in end-of-line and bag palletizing applications. With a 2.4-meter reach and a 110 kg payload capacity, it delivers up to 2,190 cycles per hour, offering a 15% speed advantage over its competitors. Its four-axis design ensures smooth, precise movements, with path accuracy of 0.11 mm and position repeatability of 0.2 mm, thanks to ABB’s QuickMove™ and TrueMove™ technologies.
The robot features a robust IP67-rated construction, low maintenance requirements, and can operate in temperatures ranging from -25°C to +45°C. The IRC5 controller and user-friendly software minimize programming time, making it an efficient and reliable solution for high-demand palletizing.
1.Faster Cycle Times
Achieves up to 2,190 cycles per hour, improving productivity by 15%.2.High Precision Handling
ABB’s QuickMove™ and TrueMove™ ensure smooth, accurate palletizing for sensitive products.
3.Complete Palletizing Solutions
Combines IRB 460 with FlexGripper and RobotStudio for optimal speed and care.
4.Low Maintenance Costs
Robust design and integrated cabling ensure long life and reduced wear.
5.Easy Programming
RobotStudio software reduces programming time by up to 80% for faster setup.
Product Gallery:
| Keyword: #Robotic Bag Palletizers, #IndustrialPalletizingRobot,#Robotic Palletiser with pick and place bags Gripper, #PalletizingRobot |
Techinical Parameters:
| Robot version | IRB 460 |
| Reach (m) | 2.4 |
| Handling capacity (kg) | 110 |
| Number of axes | 4 |
| Protection | IP67 |
| Integrated signal supply | Optional |
| Integrated air supply | Optional |
| Mounting | Floor mounted |
| Controller | IRC5 Single cabinet |
| Position repeatability RP (mm) | 0.2 |
| Path repeatability RT (mm) | 0.11 |
| Supply voltage | 200-600 V, 50-60 Hz |
| Power consumption | ISO cube 3.67 kW |
| Dimensions robot base | 1007 x 720 mm |
| Robot weight | 925 kg |
| Ambient temperature for mechanical unit | +0°C (32°F) to +45°C (113°F) during operation -25°C (-13°F) to +55°C (131°F) during transportation and storage up to +70°C (158°F) for short periods (max 24 h) |
| Relative humidity | Max. 95% |
| Noise level | < 70 dB(A) |
| Safety | Double circuits with supervisions, emergency stops and safety functions. 3-position enable device |
| Emission | EMC/EMI shielded |
| Axis 1 | +165° to -165°, 145°/s |
| Axis 2 | +85° to -40°, 110°/s |
| Axis 3 | +120° to -20°, 120°/s |
| Axis 4 | +300° to -300°, 400°/s (+150 rev. to -150 rev. max) |
