Product Description
Tavol brand tower cranes ranging from QTZ31.5 to QTZ315 has a horizontal jib frame, a jib trolley radius chang mechanism and a hydraulic self-raising mechanism. It is original in design, reliable in operation and satisfactory in shape. Equipped with necessary safety devices, these cranes show good speed-control capacity, satisfactory operat stability and high work efficiency .It can be widely used for construction of high-rise hotels, residential buildings, high-rise industrial buildings, large-span factory buildings and tower-like buildings like tall chimneys.
TAVOL have more than 30 years production history and more than 15 years of overseas business experience, can supply other capacity tower crane from 4t to 18 t .
We have an independent research and development team.All mechanical designers have a Bachelor Degree or above in mechanical engineering, more than 5 Years of experience in the cranes machinery industry, adopt the advance design concepts, and continue to innovate.
TAVOL brand tower crane applied CE certificate, the performance & technical specification is advanced in China, has reached the international advanced level .
We have exported to many countries, such as USA, Germany, Brazil, UK, Turkiye, Bangladesh, Philippines, Sri Lanka, Vietnam, Maldives, Cambodia, Oman, Saudi Arabia, Sudan, Kenya, Guinea, Georgia, Indonesia, South America etc.
| Model | QTZ63-5013 Topkit Tower Crane |
| Boom length | 50 m |
| Max load capacity | 6 t |
| Tip load capacity | 1.3t @50 m boom end |
| Mast | 1.6*1.6*2.5m |
| Hoist height | according to your demand |
| LIft speed | (a=2) 100/50/10 m/min (a=4) 50/25/5 m/min |
| Trolley speed | 40/20 m/min |
| Slewing speed | 0.65 r/min |
| Jack clmbing speed | 0.58 m/min |
| Main electric | Scheider |
| Foundation | Pre-embedded leg or # beam or Cross beam Chassis |
