CNC plasma cutting machine is a computer-controlled cutting machine that uses a plasma torch to cut through various types of metal materials with precision. These machines are commonly used in industries that require precise metal cutting for fabrication, manufacturing, and construction purposes.
They work by directing a high-velocity jet of ionized gas (plasma) at the material being cut. The plasma rapidly heats and melts the metal, while a controlled stream of gas blows the molten metal away, resulting in a clean and precise cut.
| No. | Item | Specification |
| 1 | Machine width | 4000mm |
| 2 | Effective cutting width | 3000mm |
| 3 | Rail length | 14000mm |
| 4 | Effective cutting length | 12000mm |
| 5 | Plasma cutting torch | 1 set (maximum 25mm piercing cutting thickness) |
| 6 | Plasma power | 1 set |
| 7 | Arc pressure height controller | 1 set |
| 8 | CNC flame cutting torch | 1 set (6-80mm cutting thickness) |
| 9 | Multiple strip cutting torch | 5 sets (6-80mm cutting thickness for single torch) |
| 10 | Control switch | Some |
| 11 | Idle running speed | 4000-10000mm/min |
| 12 | Cutting surface roughness | Ra≤50μm |
| 13 | Driving method | Double sides driven (servo motor) |
