CNC Router Metal Engraving Machinery
CNC Router Metal Engraving Machinery Original price was: $13,000.00.Current price is: $12,000.00.
Back to products
High-Speed Non-Woven Bag Making Machine
High-Speed Non-Woven Bag Making Machine Original price was: $36,000.00.Current price is: $35,000.00.
-8%
CNC Router Machine - Image 1
CNC Router Machine - Image 2
CNC Router Machine - Image 3
CNC Router Machine - Image 4
CNC Router Machine - Image 5
CNC Router Machine - Image 6
CNC Router Machine - Image 7
CNC Router Machine - Image 8
Click to enlarge
CNC Router Machine
CNC Router Machine - Image 2
CNC Router Machine - Image 3
CNC Router Machine - Image 4
CNC Router Machine - Image 5
CNC Router Machine - Image 6
CNC Router Machine - Image 7
CNC Router Machine - Image 8

CNC Router Machine

MACHINES IN CHINA
Only orders placed and paid through Alibaba.com can enjoy free protection by

Manufacturer Verification Applied

  • Claim a refund if your order doesn't ship, is missing, or arrives with product issues
Feature Details
Work Area (Specification) 2030 (2000mm × 3000mm)
Transport Package Plywood Case
Origin China
HS Code 8465990000

Original price was: $13,000.00.Current price is: $12,000.00.

Compare
Add to wishlist
Shipping and returns

Authorities in our business will tell in no uncertain terms that Lorem Ipsum is that huge, huge no no to forswear forever. Not so fast, I'd say, there are some redeeming factors in favor of greeking text, as its use is merely the symptom of a worse problem to take into consideration.

Product care

Anyway, you still use Lorem Ipsum and rightly so, as it will always have a place in the web workers toolbox, as things happen, not always the way you like it, not always in the preferred order.

Product Description

Detailed Photos
MAIN PARTS
7.5KW Pump CCD camera
New 1325 1530 2030 Multi Spindles CNC Router Machine Double Heads with Oscillating Knife Cutting with CCD for Wood Paper 3D Cutting Engraving New 1325 1530 2030 Multi Spindles CNC Router Machine Double Heads with Oscillating Knife Cutting with CCD for Wood Paper 3D Cutting Engraving
Delta Servo Motor and Driver 6KW Italy HSD Spindle
New 1325 1530 2030 Multi Spindles CNC Router Machine Double Heads with Oscillating Knife Cutting with CCD for Wood Paper 3D Cutting Engraving New 1325 1530 2030 Multi Spindles CNC Router Machine Double Heads with Oscillating Knife Cutting with CCD for Wood Paper 3D Cutting Engraving
Heavy Duty Frame Leyu Controller
New 1325 1530 2030 Multi Spindles CNC Router Machine Double Heads with Oscillating Knife Cutting with CCD for Wood Paper 3D Cutting Engraving New 1325 1530 2030 Multi Spindles CNC Router Machine Double Heads with Oscillating Knife Cutting with CCD for Wood Paper 3D Cutting Engraving
Oscillating Head Taiwan CSK Square Linear Guide
New 1325 1530 2030 Multi Spindles CNC Router Machine Double Heads with Oscillating Knife Cutting with CCD for Wood Paper 3D Cutting Engraving New 1325 1530 2030 Multi Spindles CNC Router Machine Double Heads with Oscillating Knife Cutting with CCD for Wood Paper 3D Cutting Engraving
Product Parameters
XYZ Travel Size 2000 X 3000 X 220mm
Max Working Size 2000 X 3000 X 220mm
Table Size 2000 X 3000mm
Transmission Type XY rack/ Z ball screw
Guide Rail Linear Guide
Table Type vacuum
Vacuum Pump 2 Pcs of 7.5KW Vacuum pump
Spindle Power 6KW Italy HSD Spindle
Knife System Oscillating + CCD camera
Spindle Speed 18000rpm
Max Travel Speed 45000mm/min
Max Work Speed 25000mm/min
Motor Taiwan Delta AC servo motor
Work Voltage AC380V  50HZ
Controller System China Leyu
Processing Accuracy ±0.05mm
Repeat Positioning Accuracy ±0.01mm
File Format G code or PLT
Overall Weight 2200KG
Overall Dimension 2300 X 4250 X 1900mm
Product Description

Applicable industries and materials
Automobile Industry: Car Mats, leather seats, Aluminum Composite
Advertising industry: Acrylic, Flag Banner, KT board display stand, Foam Board, corrugated paper showcase , Reflective Strips, MDF, Plastic
Packaging industry: EVA Foam, Kraft Paper, corrugated paper, cardboard, hollow board, Grey board

Highlights

  1. The large-size rectangular tube is welded as a whole, and the guide rail and rack mounting surface are processed by high-precision large gantry milling machine to maintain the overall stability of the machine
  2. Equipped with high-power spindle, it can not only process soft materials, but also process materials with high hardness, one machine is multi-purpose and has high efficiency
  3. Large load-bearing redundancy and long service life. The Y-axis is driven by dual motors and driven by planetary reducer, which makes the machine strong in rigidity, strong in strength and stable in rotation, so that it can run at high speed for a long time without deformation and shaking.
  4. The flexible form of the table is convenient for clamping materials, which improves the overall production efficiency
  5. Automatic refueling lubrication system, with a single touch. Regular maintenance is easy.
  6. The processing speed is fast and the efficiency is high. The processing quality is fine, the edge contour is clear, and the bottom surface is flat and smooth..
  7. The main configuration is made of imported accessories, which effectively ensures the overall performance of the machine tool.
  8. Safety assurance, in strict compliance with CE electrical standards for circuit design and production, all moving parts have safe and reliable protection devices.
