Crawler Rotary Hydraulic Construction Engineering Mine Drill Rotary Small Auger Static Pile Machine Pilling Driver Drilling Equipment
Crawler Rotary Hydraulic Construction Engineering Mine Drill Rotary Small Auger Static Pile Machine Pilling Driver Drilling Equipment - Image 2
Crawler Rotary Hydraulic Construction Engineering Mine Drill Rotary Small Auger Static Pile Machine Pilling Driver Drilling Equipment - Image 3
Crawler Rotary Hydraulic Construction Engineering Mine Drill Rotary Small Auger Static Pile Machine Pilling Driver Drilling Equipment - Image 4
Crawler Rotary Hydraulic Construction Engineering Mine Drill Rotary Small Auger Static Pile Machine Pilling Driver Drilling Equipment - Image 5
Crawler Rotary Hydraulic Construction Engineering Mine Drill Rotary Small Auger Static Pile Machine Pilling Driver Drilling Equipment - Image 6

Crawler Rotary Hydraulic Construction Engineering Mine Drill Rotary Small Auger Static Pile Machine Pilling Driver Drilling Equipment

MACHINES IN CHINA
Only orders placed and paid through Alibaba.com can enjoy free protection by

Manufacturer Verification Applied

  • Claim a refund if your order doesn't ship, is missing, or arrives with product issues
Feature Details
Drilling Diameter 500 mm – 1600 mm
Drilling Depth 30 m
Power Head Max Torque 130 kN.m
Rotary Speed 10 – 50 r/min
Max Working Pressure 32 MPa
Bit Type Diamond Bit / Standard Augers



Original price was: $51,000.00.Current price is: $50,000.00.

Compare
Add to wishlist
Shipping and returns

Authorities in our business will tell in no uncertain terms that Lorem Ipsum is that huge, huge no no to forswear forever. Not so fast, I'd say, there are some redeeming factors in favor of greeking text, as its use is merely the symptom of a worse problem to take into consideration.

Product care

Anyway, you still use Lorem Ipsum and rightly so, as it will always have a place in the web workers toolbox, as things happen, not always the way you like it, not always in the preferred order.

Product Description

Product Description

HF30+ crawler type rotary drilling rig adopts pressurized drilling mode, enabling rotary drilling depth is 30m, matching the different specifications of drilling tools, pile hole diameter ranges from 500-1600mm. It has high drilling efficiency, and after construction, it can quickly move to next working site. Flexible, convenient and efficient, it is a national high-speed rail construction-specific piling machinery equipment.

Product Parameters



Type HF330 Rotary Drilling Rig
Drilling depth 30m
Hole diameter 500-1600 mm
Engine Brand Cummins
Power 210HP (154KW)
Power Head Torque 130 KN ·m
Rotating speed 10-50 r/min
Main Winch Maximum lifting force 150 KN
Lifting speed 70 m/ min
Wire rope diameter 24 mm
Vice Winch Maximum lifting force 30 KN
Lifting speed 55 m/ min
Wire rope diameter 14 mm
Pressurized Cylinder Maximum pressure 120 KN
Max lifting speed 120 KN
stroke 2500 mm
Walk Walk speed 5 km/h
Maximum grade 30 °
System pressure 32 Mpa
Weight 28 / 30 T
Working Radius 4.3 m
Dimensions (L * W * H) 11.5 m*3 (2.8-3.6)m*3.55m
