Asphalt Mixing Plant / 80t 120t 160t 240t / Bitumen / Asphalt Batching Plant
Manufacturer Verification Applied
- Claim a refund if your order doesn't ship, is missing, or arrives with product issues
Original price was: $31,000.00.$30,000.00Current price is: $30,000.00.
Authorities in our business will tell in no uncertain terms that Lorem Ipsum is that huge, huge no no to forswear forever. Not so fast, I'd say, there are some redeeming factors in favor of greeking text, as its use is merely the symptom of a worse problem to take into consideration.
Anyway, you still use Lorem Ipsum and rightly so, as it will always have a place in the web workers toolbox, as things happen, not always the way you like it, not always in the preferred order.
| Feature | Details |
| Moving Type | Fixed & Mobile (Highly Adaptable) |
| Object Application | Asphalt Concrete Pavement Construction |
| Certification | ISO 9001:2000, CE |
| Technical Support | Global On-site Services Provided |
| Condition | New |
Product Description
2. Airport & Port Projects: Pavement material supply for runways, docks, and logistics zones
3. Infrastructure Development: Reliable asphalt mix for bridges, tunnels, and interchanges
4. Industrial Parks: Surface paving for factory zones, heavy-load transport routes
5. Maintenance & Repair: On-demand asphalt for road resurfacing and patch repairs
2. Burner System: High-efficiency, low-emission burner compatible with multiple fuel types
3. Drying Drum: Energy-efficient drying system with advanced heat exchange and dust control
4. Control System: Fully automated PLC or SCADA-based control panel with real-time diagnostics and remote monitoring
5. Cold Aggregate Feeding: Multiple-bin cold feeder with variable speed control for precise ingredient proportioning
6. Dust Collection: Multi-stage filtration (baghouse or cyclone) system to meet environmental regulations
7. Bitumen Supply: Heated bitumen tanks with automatic temperature and level control
|
Model
|
RLB-80
|
RLB-120
|
RLB-160
|
RLB-240
|
|
(L×W×H)(m)
|
32*32*16
|
36*33*16
|
34*30*19
|
45*35*28
|
|
Aggregate measuring accuracy
|
1000kg±0.5%
|
1500kg±0.5%
|
2000kg±0.5%
|
3000kg±0.5%
|
|
Cement measuring accuracy
|
150kg±0.3%
|
225kg±0.3%
|
300kg±0.3%
|
450kg±0.3%
|
|
Asphalt measuring accuracy
|
100kg±0.2%
|
150kg±0.2%
|
200kg±0.2%
|
300kg±0.2%
|
|
Volume(m³)
|
4×8m³
|
4×10m³
|
5×10m³
|
5×15m³
|
|
Drum size(m)
|
Ø1.7×6.3
|
Ø1.92×8
|
Ø1.98 ×9.8
|
Ø2.5×9
|
|
Mixer capacity(kg)
|
1000
|
1500
|
2000
|
3000
|
|
Total power(kw)
|
240
|
370
|
420
|
548
|
|
Rated output(t/h)
|
80
|
120
|
160
|
180-240
|
|
Transport
|
Containers
|
Containers
|
Containers
|
Bulk carriers
|
