High Performance ABC Three-Layer Film Blowing Machine for Snack Packaging Bags
High Performance ABC Three-Layer Film Blowing Machine for Snack Packaging Bags Original price was: $28,400.00.Current price is: $27,400.00.
-1%
ABC Three-Layer Co-Extrusion Film Blowing Machine with K-Design Automatic Air Ring ABC Blown Film Production Line - Image 1
ABC Three-Layer Co-Extrusion Film Blowing Machine with K-Design Automatic Air Ring ABC Blown Film Production Line - Image 2
ABC Three-Layer Co-Extrusion Film Blowing Machine with K-Design Automatic Air Ring ABC Blown Film Production Line - Image 3
ABC Three-Layer Co-Extrusion Film Blowing Machine with K-Design Automatic Air Ring ABC Blown Film Production Line - Image 4
ABC Three-Layer Co-Extrusion Film Blowing Machine with K-Design Automatic Air Ring ABC Blown Film Production Line - Image 5
ABC Three-Layer Co-Extrusion Film Blowing Machine with K-Design Automatic Air Ring ABC Blown Film Production Line - Image 6
ABC Three-Layer Co-Extrusion Film Blowing Machine with K-Design Automatic Air Ring ABC Blown Film Production Line - Image 7
ABC Three-Layer Co-Extrusion Film Blowing Machine with K-Design Automatic Air Ring ABC Blown Film Production Line - Image 8
ABC Three-Layer Co-Extrusion Film Blowing Machine with K-Design Automatic Air Ring ABC Blown Film Production Line - Image 9
ABC Three-Layer Co-Extrusion Film Blowing Machine with K-Design Automatic Air Ring ABC Blown Film Production Line - Image 10
ABC Three-Layer Co-Extrusion Film Blowing Machine with K-Design Automatic Air Ring ABC Blown Film Production Line - Image 11
Click to enlarge
ABC Three-Layer Co-Extrusion Film Blowing Machine with K-Design Automatic Air Ring ABC Blown Film Production Line
ABC Three-Layer Co-Extrusion Film Blowing Machine with K-Design Automatic Air Ring ABC Blown Film Production Line - Image 2
ABC Three-Layer Co-Extrusion Film Blowing Machine with K-Design Automatic Air Ring ABC Blown Film Production Line - Image 3
ABC Three-Layer Co-Extrusion Film Blowing Machine with K-Design Automatic Air Ring ABC Blown Film Production Line - Image 4
ABC Three-Layer Co-Extrusion Film Blowing Machine with K-Design Automatic Air Ring ABC Blown Film Production Line - Image 5
ABC Three-Layer Co-Extrusion Film Blowing Machine with K-Design Automatic Air Ring ABC Blown Film Production Line - Image 6
ABC Three-Layer Co-Extrusion Film Blowing Machine with K-Design Automatic Air Ring ABC Blown Film Production Line - Image 7
ABC Three-Layer Co-Extrusion Film Blowing Machine with K-Design Automatic Air Ring ABC Blown Film Production Line - Image 8
ABC Three-Layer Co-Extrusion Film Blowing Machine with K-Design Automatic Air Ring ABC Blown Film Production Line - Image 9
ABC Three-Layer Co-Extrusion Film Blowing Machine with K-Design Automatic Air Ring ABC Blown Film Production Line - Image 10
ABC Three-Layer Co-Extrusion Film Blowing Machine with K-Design Automatic Air Ring ABC Blown Film Production Line - Image 11

ABC Three-Layer Co-Extrusion Film Blowing Machine with K-Design Automatic Air Ring ABC Blown Film Production Line

MACHINES IN CHINA
Only orders placed and paid through Alibaba.com can enjoy free protection by

Manufacturer Verification Applied

  • Claim a refund if your order doesn't ship, is missing, or arrives with product issues
Feature Details
Model A-ABC (Three-Layer Co-extrusion)
Screw Configuration $85\text{ mm}$ – $120\text{ mm}$ – $85\text{ mm}$
Max Output $600\text{ kg/H}$
Max Folding Width $2500\text{ mm}$
Film Thickness $0.02\text{ mm}$ – $0.2\text{ mm}$
Die Diameter $\phi 550\text{ mm}$
Main Motors $250\#$ / $315\#$ / $250\#$ (High-Torque)
Gearbox Power $75\text{ kW}$ / $90\text{ kW}$ / $75\text{ kW}$
Automation Fully Computerized with IBC & EPC
Dimensions (LWH) $15.7 \times 8.4 \times 14 \text{ Meters}$
HS Code 84773090

Original price was: $97,000.00.Current price is: $96,000.00.

Compare
Add to wishlist
Shipping and returns

Authorities in our business will tell in no uncertain terms that Lorem Ipsum is that huge, huge no no to forswear forever. Not so fast, I'd say, there are some redeeming factors in favor of greeking text, as its use is merely the symptom of a worse problem to take into consideration.

Product care

Anyway, you still use Lorem Ipsum and rightly so, as it will always have a place in the web workers toolbox, as things happen, not always the way you like it, not always in the preferred order.

Product Description

Automatic ABC(IBC)Three Layers Co-extrusion Center Gap Winding System Film Blowing machine
ABC Three-Layer Co-Extrusion Film Blowing Machine with K-Design Automatic Air Ring ABC Blown Film Production LineABC Three-Layer Co-Extrusion Line are designed developed by our corporation according to market need.It used for blowing LDPE/HDPE/LLDPE packaging films and it has good insulation,for instance holding temperature,antihumid,antibreeze,anti-rain,anti-rost,insulation oxygen,oil resistive, and so used for light and heavy-duty packaging.For example fresh fruits,meat-feeding,salt vegetables, fresh milk, liquid drink.The most important ,this film blowing machine are equipped with IBC system to improve the transparency and uniformity of film products, and significantly increased the output of the machine.
ABC Three-Layer Co-Extrusion Film Blowing Machine with K-Design Automatic Air Ring ABC Blown Film Production Line

Model 3L-50-55-50/1400 3L-55-65-55/1600/1800 3L-65-75-65/2200 3L-85-95-85/2400 3L-95/110/95-/2800
Width of the film 600-1200mm 800-1400/1000-1600mm 1400-2000mm 1600-2200mm 2000-2600mm
Thickness of the film LDPE 0.02-0.2mm
Output 250kg/h 300kg/h 380kg/h 600kg/h 700kg/h
According to different width, thickness of film,die size and raw material characteristics to change
Raw material HDPE/LDPE/LLDPE/MDPE/EVA
Diameter of screw Φ50/55/50 Φ55/65/55 Φ65/75/65 Φ85/95/85 Φ95/110/95
L/D ratio of screw 32:1(With force feeding)
Gear box 173# 200# 173# 200# 225# 200# 225# 250# 225# 250#315#250# 280/330/280
Main motor 30kw37kw/30kw 37kw/45kw/37kw 45kw/55kw/45kw 75kw/90kw/75kw 90/160/90
Die diameter Φ 300mm Φ350mm/400mm Φ500mm Φ550mm Φ650mm

Detailed Photos

ABC Three-Layer Co-Extrusion Film Blowing Machine with K-Design Automatic Air Ring ABC Blown Film Production Line
ABC Three-Layer Co-Extrusion Film Blowing Machine with K-Design Automatic Air Ring ABC Blown Film Production Line
ABC Three-Layer Co-Extrusion Film Blowing Machine with K-Design Automatic Air Ring ABC Blown Film Production Line
ABC Three-Layer Co-Extrusion Film Blowing Machine with K-Design Automatic Air Ring ABC Blown Film Production Line
ABC Three-Layer Co-Extrusion Film Blowing Machine with K-Design Automatic Air Ring ABC Blown Film Production Line
ABC Three-Layer Co-Extrusion Film Blowing Machine with K-Design Automatic Air Ring ABC Blown Film Production Line
ABC Three-Layer Co-Extrusion Film Blowing Machine with K-Design Automatic Air Ring ABC Blown Film Production Line
