Product Description
The following is a comprehensive introduction to Chengli concrete mixer trucks, along with a detailed analysis that takes into account industry characteristics and the enterprise’s background:
I. Company Background and Brand Positioning
Chengli Special Vehicles Overview
Chengli Special Vehicles Co., Ltd. (referred to as “Chengli”) is one of the leading enterprises in the field of special vehicles in China. Its headquarters is located in Suizhou, Hubei Province, and it holds the special vehicle production qualification approved by the National Ministry of Industry and Information Technology. The products cover various fields such as sanitation, engineering, and emergency response, and concrete mixer trucks are one of the core products in its construction machinery sector.
Market positioning
Chengli mixer trucks are renowned for their high cost-effectiveness and adaptable design. They are mainly targeted at small and medium-sized construction enterprises, concrete suppliers, and urban and rural construction projects, while also considering economic efficiency and basic functional requirements.
II. Product Core Features
1. Structure and Performance
Chassis Configuration: Mostly uses domestic mature chassis such as Dongfeng and Jiefang, compatible with engines like Yuchai and Weichai. The power range covers 270-400 horsepower, suitable for complex construction site conditions.
Bucket Design:
Capacity 8-12 cubic meters (common models), optimized inclination ensures smooth discharge.
Blades are made of wear-resistant alloy steel, extending service life.
Hydraulic System: International brands (such as German Rexroth) or first-class domestic hydraulic pumps/motors. The mixing speed can be adjusted (6-12 revolutions per minute).
2. Technical Highlights
Lightweight Design: Reduces weight through the application of high-strength steel, in line with national overloading regulations.
Intelligent Control: Some high-end models are equipped with GPS positioning, fuel consumption monitoring, and fault diagnosis systems.
Environmental Compliance: Meets the national sixth emission standards, and optional anti-leakage device can reduce pollution.
| Main technical information: | |
| Model No. | CLW5040TQZHDPPP-A8 Concrete Mixer Truck |
| Certification | ISO9001,CCC,TS6949,CE,EPA,EEC,ROHS |
| Emission Standard | Euro2/3/4/5/6 |
| Gross Vehicle Weight(kg) | 31000 |
| Curb Weight(kg) | 13870 |
| Rated Load Capacity(kg) | 17000 |
| Wheelbase(mm) | 1800+3050+1350, |
| Overall Size(L*W*H) | 9650×2500×3950 |
| Axle Load | 6500/7000/17500 |
| Drive Type | Left/Right hand |
| Drive Wheel | 6*4/8*4/8*6 |
| Fuel | Diesel |
| Origin | Hubei,China |
| Production Capacity | 50000 Pieces/year |
| Trademark | CHENGLI |
| Transport Package | Need |
| HS Code | 8705400000 |
| Chassis Parameters | |
| Chassis Brand | HOWO brand |
| Chassis Model | ZZ1317N306GF1 Type II |
| Tire specification | 12R22.5 18PR,11.00R20 |
| Gear Box | 8/10/12-speed manual |
| Transmission | Manual |
| Additional information | Framework Material Q235 |
| Engine Parameters: | |
| Manufacturer | WOHO |
| Model | MC07H.35-60/MC09.35B-60 |
| Horse Power(hp) | 350/353 |
| Displacement/Power(ml) | 7360/8765 |
| Engine Capacity | 257/260 |
| Driving performance | |
| Maximum speed(km/h) | 82 |
| Maximum climbing angle | 30% |
| Braking distance | ≤40m |
| Approach Angle/Departure Angle | 25/23 |
| Number of tires | 10/12/14 |
| Upper garment size | |
| Carrier volume | 8/10/12/15 cubic meters |
